Plug; 4-pole; 1,50 mm²; gray Wago Premium

Descriere

Descriere produs

Note on Contact Resistance: approx. 1 mΩ of contact resistance
 approx. 0.25 mΩ contact transition plug/socket;Ratings per: IEC/EN 60664-1;Tesiune nominala (III/3): 400; VTensiune nominala de supratensiune (III/3): 6; kVCurent nominal: 16; ANote on Curent nominal: 13 A for 3-pole load 10 A for 4-pole load;Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3;Tensiune nominala UL 1977: 600; VCurent nominal UL 1977: 12; ATehnologie conexiune: Push-in CAGE CLAMP®;Tip actionare: Operating tool; Push-in;Nominal cross-section: 1,5 mm²;Solid conductor: 0,25 … 1,5 mm² / 22 … 16 AWG;Solid conductor; push-in termination: 0,75 … 1,5 mm² / 20 … 16 AWG;Stranded conductor: 0,25 … 1 mm² / 22 … 18 AWG;Fine-stranded conductor: 0,25 … 1,5 mm² / 22 … 16 AWG;Fine-stranded conductor; with insulated ferrule: 0,25 … 0,75 mm² / 22 … 20 AWG;Fine-stranded conductor; with uninsulated ferrule: 0,25 … 0,75 mm² / 22 … 20 AWG;Fine-stranded conductor; with ferrule; push-in termination: 0,75 mm² / 20 AWG;Strip length: 9 mm / 0.35 inch;Note (strip length): see also packaging or instructions;Numar poli: 4;Numar total de conexiuni: 4;Total number of potentials: 4;Conductor entry direction to mating direction: 0; °Distanta intre pini: 4,4 mm / 0.173 inch;Latime: 19,2 mm / 0.756 inch;Inaltime: 11,7 mm / 0.461 inch;Adancime: 34,1 mm / 1.343 inch;Coding: B;Mating force of a plug-in connection: approx. 20 … 70 N (depending on pole number);Retention force of a plug-in connection: Locked: > 80 N;Unmating force of a plug-in connection: Unlocked: approx. 20 … 70 N (depending on pole number);Number of mating cycles: 200, without resistive load100, with resistive load IN = 16 A, tested (1.5 mm²/16 AWG);Marking: 1 2 3 4;Protection type: IP20;Note on protection type: IP40 when mated with strain relief housing;Potential marking: 1 2 3 4;Tip contact (pluggable connector): Conector tata/fisa;Connector (connection type): for conductor;Mismating protection: Yes;Locking of plug-in connection: locking lever;Locking lever: retrofittable;Culoare: gray;Material izolator: Polyamide 66 (PA 66);Clamping spring material: Chrome nickel spring steel (CrNi);Contact material: Copper or copper alloy (surface-treated);Fire load: 0,099; MJGreutate: 4,6; gProcessing temperature: -5 … +40 °C;Continuous operating temperature: -35 … +85 °C;Note on continuous operating temperature: Insulating parts for temperatures ≤ 105 °C;Product Group: 20 (WINSTA);Tip ambalare: BOX;Tara de origine: PL;GTIN: 4055143523660;Customs tariff number: 85366990990;
